| SR.NO. |
CHARACTERISTICS |
ISO TEST METHODS |
TILES REQUIREMENT AS PER IS 13006 : 2012 GROUP B lB |
OUR VALUE |
| DIMENSION & SURFACE QUALITY |
| 1 |
Deviation in Length & Width |
ISO 10545-2 |
+/-0.5% |
+/-0.2% |
| 2 |
Deviation in Thickness |
ISO 10545-2 |
+/-5% |
+/-3% |
| 3 |
Straightness Of Sides |
ISO 10545-2 |
+/-0.5% |
+/-0.2% |
| 4 |
Rectangularity |
ISO 10545-2 |
+/-0.5% |
+/-0.2% |
| 5 |
Surface Flatness |
ISO 10545-2 |
+/-0.5% |
+/-0.2% |
| PHYSICAL & THERMAL PROPERTIES |
| 1 |
Water Absorption |
ISO 10545-3 |
<0.50% |
<0.04% |
| 2 |
Mohs Hardness |
EN-101 |
Min.5 |
Min.5 |
| 3 |
Flexural Strength |
ISO 10545-4 |
>35N/mm² |
>40N/mm² |
| 4 |
Skid Resistance |
ISO 10545-17 |
>0.4 |
>0.4 |
| 5 |
Breaking Strength |
ISO 10545-11 |
>1113N |
>1800N |
| 6 |
Frost Resistance |
ISO 10545-12 |
Frost Proof |
Frost Proof |
| 7 |
Thermal Shock Resistance |
ISO 10545-9 |
No Damage |
No Damage |
| 8 |
Moisture Expansion |
ISO 10545-10 |
Nil |
Nil |
| 9 |
Resistance to Surface Abrasion |
ISO 10545-7 |
Abrasion class shall be specified by the manufacturer |
PE IV |
| CHEMICAL PROPERTIES |
| 1 |
Chemical Resistance |
ISO 10545-13 |
No Damage |
No Damage |
| 2 |
Color Resistance |
ISO 10545-16 |
No Damage |
No Damage |
| 3 |
Stain Resistance |
ISO 10545-14 |
Resistant |
Resistant |
